Orion Printed Circuit Board Photo Gallery
Name: OR-IOC-IEEE488
Revision: B
Year: 1984
Description: I/O Controller. Connected to the OR-PIC, OR-MUX or OR-COM via a 34 pin ribbon cable on the front of the board. Included an IEEE488 interface and had four RS232 interfaces.
